Nimonic Alloy 263 Mechanical Properties

The mechanical properties of Nimonic Alloy 263™ are provided below.

PropertiesMetricImperial
Tensile strength (precipitation hardened, value at room temperature)940 MPa136000 psi
Yield strength (@strain 0.200%, precipitation hardened, value at room temperature)550 MPa79800 psi
Elongation at break (precipitation hardened)39%39%

Nimonic Alloy 263 Thermal Properties

The thermal properties of Nimonic Alloy 263™ are given below.

PropertiesMetricImperial
Thermal expansion co-efficient (@21-100°C/69.8-212°F)10.3 µm/m°C5.72 µin/in°F
Thermal conductivity11.7 W/mK81.2 BTU in/hr.ft².°F
  • AMS 5872
  • AMS 5886
  • DIN 2.4650

Category:

Nimonic 263 Nickel Based Superalloy

NIMONIC® alloy 263 (UNS N07263/W. Nr. 2.4650), an air melted nickel-base alloy, was developed by Rolls- Royce (1971) Ltd. to provide a sheet material which could be readily fabricated and would offer improved ductility in welded assemblies to replace NIMONIC alloy 80A. It was designed as sheet material to meet specific design criteria in terms of proof stress and creep strength.

Nimonic 263® is an age-hardenable nickel-cobalt chromium-molybdenum alloy designed specifically to combine good aged strength properties with excellent fabrication characteristics in the annealed condition. While its strength at elevated temperatures is not quite as high as Waspaloy® or Rene 41, it is far easier to form or weld than these alloys.

Alloy C263 plate – Nimonic 263® plate exhibits excellent intermediate temperature tensile ductility, and is not normally subject to strain age cracking problems common for other gamma prime strengthened alloys. This grade is typically used for applications up to about 1650°F (900°C). This grade combines properties which make it suitable for a variety of fabricated components in both aircraft turbine engine and land-based turbine applications.

It is now available in all standard forms. The welding techniques for this alloy are similar to those in common use for other age-hardenable nickel- base alloys.

During salvage welding operations, a pre-weld heat-treatment is not necessary on age-hardened assemblies but a subsequent age-hardening treatment is desirable after all salvage welding is completed. The material will age in service if temperatures are above 750°C.

Nimonic 263 Chemical Composition:

ElementLimiting Chemical Composition (%)
Carbon0.04%-0.08%
Silicon0.40% max
Manganese0.60% max
Sulfur0.007% max
Silver0.0005% max
Aluminum0.60% max
Boron0.005% max
Bismuth0.0001% max
Cobalt19.0%-21.0%
Chromium19.0%-21.0%
Copper0.20% max
Iron0.7% max
Molybdenum5.6%-6.1%
Lead0.0020% max
Titanium1.9%-2.4%
Aluminum and titanium2.4%-2.8%
NickelBalance*



Nimonic 263 Fabrication and Working Instructions:

Nimonic 263 can be hot worked in the temperature range of 1742-2102°F (950-1150°C). Cold forming mechanical properties, on the other hand, are given in the following table:

0.1% proof stress343 MPa
0.2% proof stress355 MPa
0.5% proof stress369 MPa
Tensile strength788 MPa
Elongation on 50 mm, %59.7
Hardness195 HV
Mean grain sizeASTM 6.5
Erichsen value12.8 mm
Shear strength588 MPa
Ratio of shear to tensile strength0.75

Please note that the data is obtained using annealed sheet 0.5-1.2 mm thick, using annealing technique of 3 minutes at 1190°C by fluidized bed quenching.

Annealing of Nimonic 263 is required during manipulations with the alloy. The following instructions should be followed regarding the shape or form:

  • Bar or heavy section is usually softened by a heat treatment that lasts two hours at 2102°F (1150°C);
  • Annealing of sheets should last 15 minutes at a temperature range of 1922-2012°F (1050-1100°C), followed by rapid cooling. For sheets, fluidized bed quenching can also be used.

Depending on the joint configuration and material thickness, Nimonic alloy 263 can be readily welded by argon shielded automatic and manual T.I.G and M.I.G processes. For all argon shielded welding processes the filler metal is the AMS 5966 specification (Nimonic filler metal 263). In the few next bulleted points, you can see all the different argon shielded welding processes:

  • Automatic T.I.G. welding can be employed on parts with a thickness of up to 3.25 mm, and only for simple butt joints without any special shaping. The Nimonic filler metal 263 should be used for parts thicker than 1.6 mm, while welding can be obtained without filler metal for parts that are thinner than 1.6 mm;
  • Manual T.I.G. welding should be employed on more complicated joints with special shaping and is recommended to be used on thicknesses of up to 4.8 mm;
  • I.G. welding can be used on all section thicknesses, but it is best to be used on thicknesses above 4.8 mm. Besides, it should be used over manual T.I.G. if a lot of welding is required. Both spray and dip transfer conditions can be used in this process.

Other welding and joining processes that can be used on Nimonic alloy 263, but to a lesser extent:

  • Resistance spot, stitch and seam welding;
  • Flash-butt welding used for the manufacture of gas turbine rings.

Nimonic 263 Physical Properties:

Density0.302 lb/in3
8.36 g/cm3
Melting RangeLiquidus temperature 2471°F (1355°C)
Solidus temperature 2372°F (1300°C)
Specific Heat at J/kg862°F (461°C)

Nimonic 263 Mechanical Properties:

Tensile strength (precipitation hardened at room temperature)940 MPa
136,000 psi
Yield strength (@strain 0.200%, precipitation hardened, value at room temperature)550 MPa
79,800 psi
Elongation at break (precipitation hardened)39%

Nimonic 263 Thermal Properties:

Thermal expansion coefficient at 69.8-212°F (21-100°C)5.72 µin/in°F
10.3 µm/m°C
Thermal conductivity81.2 BTU in/hr.ft².°F
11.7 W/mK

Nimonic 263 Heat Treatment:

Typically, Nimonic alloy 263 should be given a two-stage heat-treatment carried out in the air, or more specifically solution treatment and age hardening. Here are all the details on recommended heat treatments for different forms of the alloy:

  • Extruded or forged bars and a section for forging and /or machining – 1.5-2.5h at 2102°F (1150°C)/WQ for solution treatment and 8 h at 1472°F (800°C)/AC for aging treatment;
  • Hot rolled sheet – 1.5h at 2102°F (1150°C)/WQ for solution treatment and 8 h at 1472°F (800°C)/AC for aging treatment;
  • Cold-rolled sheet and cold-drawn section (including tube) – 3-10 min at 2102°F (1150°C)/FBQ or WQ for solution treatment and 8 h at 1472°F (800°C)/AC for aging treatment.
